Specifications
Network Protocol and Standards Compatibility
· IEEE 802.3 10BASE-T
· IEEE 802.3u 100BASE-TX
· IEEE 802.3ab 1000BASE-T
· IEEE 802.3z 1000BASE-X
· IEEE 802.3x full-duplex flow control
Power Supply
Power consumption: 7.68W maximum
Network Ports
8 10/100/1000 Mbps auto sensing Gigabit Ethernet (GS108T)
Physical Specifications
· Dimensions:(W x D x H) 235 x 101 x 26 mm (9.3 x 4.0 x 1.0 in)
· Weight: 0.69 kg (1.52 lb)
Performance Specifications
· Forwarding modes: Store-and-forward
· Bandwidth: 16 Gbps full duplex
· Network latency: Less than 20 microseconds for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission
· Buffer memory: 128 KB embedded memory per unit
· Address database size: 8,000 media access control (MAC) addresses per system
· Addressing: 48-bit MAC address
· Mean time between failure (MTBF): 108,016 hours (~12 years)
· Acoustic noise: 0 dB
Electromagnetic Emissions
· CE mark, commercial
· FCC Part 15 Class A
· VCCI Class A
· C-Tick
Environmental Specifications
· Operating temperature: 32° to 104° F (0° to 50° C)
· Storage temperature: -4° to 158° F (-20° to 70° C)
· Operating humidity: 90% maximum relative humidity, non-condensing
· Storage humidity: 95% maximum relative humidity, non-condensing
· Operating altitude: 10,000 ft (3,000 m) maximum
· Storage altitude: 10,000 ft (3,000 m) maximum
LEDs
· Per port: (10/100 and Gigabit): Link/ Activity, Speed
· Per device: Power
Electromagnetic Immunity
EN 55024
Safety
· CE mark, commercial
· cUL IEC950/EN60950
Administrative Switch Management
· IEEE 802.1Q Static VLAN (256 groups, Static)
· Port-based VLAN (8 groups)
· IEEE 802.1p Class of Service (CoS)
· Port-based QoS
· DSCP-based QoS
· IEEE802.3ad Link Aggregation (manual or LACP)
· IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
· IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
· SNMP v1, v2c
· RFC 1213 MIB II
· RFC 1643 Ethernet Interface MIB
· RFC 1493 Bridge MIB
· RMON group 1, 2, 3, 9
· RFC 2131 DHCP client
· IEEE 802.1x with Guest VLAN
· Jumbo frame support
· Port-based security by locked MAC addresses
· Storm control for broadcast, multicast and unknown unicast packets
· IGMP Snooping v1/v2
· Port-based ingress & egress rate limiting
· SNTP
· Port Mirroring Support (Many to one)
· Web-based configuration
· Configuration Backup/Restore
· Password Access Control
· RADIUS Support
· Syslog
· Firmware upgradeable
| |
| |
|
|
|
|
| |
|
