Product Description
GENERAL
Device Type Radio access point
Ruggedized Design Outdoor
Width 23 cm
Depth 20 cm
Height 5 cm
Weight 1.35 kg
Localisation Australia, New Zealand
NETWORKING
Form Factor External
Connectivity Technology Wireless
Data Transfer Rate 1.9 Gbps
Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Spread Spectrum Method OFDM, DSSS
Network / Transport Protocol NTP, DHCP, Bonjour
Remote Management Protocol SNMP 3, HTTP, HTTPS
Frequency Band 2.4 GHz, 5 GHz
Capacity Connection / user qty: 200 Concurrent users per radio: 50 Maximum number of access points (per cluster): 16 Maximum number of configured SSIDs: 16 Active clients (per cluster): 960 VLANs supported: 32
Status Indicators Status
Features Auto-sensing per device, load balancing, VLAN support, Syslog support, E-mail alert, IPv6 support, DFS support, Wireless Distribution System (WDS) support, firmware upgradable, surge protection, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, Auto Channel Select (ACS), event log, Access Control List (ACL) support, Quality of Service (QoS), Multiple SSID support, wireless bridge mode, reset button, IPv4 support, 3T3R MIMO technology, rogue access point detection, DHCP client, Energy Efficient Ethernet, rugged, security lock slot (cable lock sold separately), 802.1x authentication, VoIP support, Link Aggregation, network diagnostics, SSID to VLAN mapping
Encryption Algorithm WPA, WPA2, WPA-Enterprise, WPA2-Enterprise
Authentication Method RADIUS, Radio Service Set ID (SSID)
Compliant Standards IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11e, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac
AERIAL
Antenna Internal
Antenna Qty 6
EXPANSION / CONNECTIVITY
Interfaces 1 x 1000Base-T (PoE) - RJ-45 1 x 1000Base-T - RJ-45
MISCELLANEOUS
Included Accessories Wall/ceiling mounting plate
Cables Included 1 x network cable
Compliant Standards ICES-003, EN 300.328, EN 301.489.1, EN 301.489.17, FCC Part 15.247, RSS-210, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, EN 301.893, FCC Part 15.407, IP66, CAN/CSA C22.2 No. 60950-1, EMI, AS/NZS 4268.2003
POWER
Power Over Ethernet (PoE) Supported PoE
Power Consumption Operational 18 Watt
SOFTWARE / SYSTEM REQUIREMENTS
OS Provided Linux
MANUFACTURER WARRANTY
Service & Support Limited warranty - lifetime
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 0 C
Max Operating Temperature 40 C
Humidity Range Operating 10 - 85% (non-condensing)
PROCESSOR / MEMORY / STORAGE
RAM 256 GB
Flash Memory 128 MB
