Product Description
NUC I7-6770HQ MINI PC DESKTOP KIT 2 X M.2 SATA THUNDERBOLT3 4 X USB3.0 TRIPLE DISPLAY HDMI M-DP DP GB LAN WIFI VESA
Mini PC Intel NUC Kit BOXNUC6I7KYK4 (INCLUDED IN THE BOX NUC Kit, AC Power Adaptor, Installation guide, additional Plain Black NUC Replaceable LID)
6th Generation Intel Core i7-6770HQ processor (2.6 to 3.5 GHz Turbo, Quad Core, 6 MB Cache, 45W TDP)
Intel Iris Pro graphics 580
Thunderbolt 3 (40Gbps) with USB 3.1 and DP1.2 over USB-C
Support for DDR4 memory, up to 32GB at 2133+ MHz
Support for dual M.2 slots for SATA3/PCIe x4 Gen 3 NVMe/AHCI SSDs
Full-size HDMI 2.0 (4K 60Hz) port and Mini DisplayPort version 1.2 (4K 60Hz) supporting 8 channel audio (7.1 surround sound)
Intel Dual Band Wireless-AC 8260 wifi (802.11 ac) and Bluetooth 2 pre-installed
SD card slot (up to 512GB)
Four USB 3.0 ports (including one charging port)
Intel HD Audio via Headphone/Microphone jack
Intel Gigabit LAN
Consumer infrared sensor
Ships with two lids – one with a skull logo, one plain mate black (Support for user-replaceable third-party lids)
Dimension: 216mm x 116mm x 23m – an incredibly small .69L
Other features: Includes Thunderbolt 3 (40Gbps) USB 3.1 Gen 2 (10Gbps) and DP 1.2 via USB-C; also includes SDXC card slot
I/O Specifications
USB Revision 2.0, 3.0, 3.1
# of USB Ports 9
USB 2.0 Configuration (External + Internal) 0 + 2
USB 3.0 Configuration (External + Internal) 3B 2F + 2I
Total # of SATA Ports 2
Max # of SATA 6.0 Gb/s Ports 2
RAID Configuration 2x M.2 SATA/PCIe SSD (RAID-0 RAID-1)
Audio (back channel + front channel) 7.1 digital; L+R+mic (F); L+R+TOSLINK (R)
Integrated LAN 10/100/1000
Integrated Wifi Intel® Wireless-AC 8260 + BT 4.2
Integrated Bluetooth Yes
Consumer Infrared Rx Sensor Yes
S/PDIF Out Connector TOSLINK
Additional Headers CEC, 2x USB2.0, 2x USB 3.0, FRONT_PANEL
The Intel NUC Kit NUC6i7KYK with 6th generation Intel Core i7 processor and Intel Iris Pro Graphics unleashes maximized performance for intense game play. We've created a wicked new look, along with a redesigned chassis that lets you take full advantage of every GHz of the quad-core processor without overheating, making the NUC6i7KYK totally cool. Literally.
Whether you use the NUC to train your dragon or bring down your enemy's nexus, or to visualize complex information like Monte Carlo simulations, you've got the performance you need, including 30x better 3D graphics for higher resolution and faster frame rates. And with Thunderbolt 3 you get four times the data and twice the video bandwidth of any other cable which means you have blazing fast throughput for an external RAID stack or an external graphics engine.
Work and play in high resolution with Intel Iris Pro Graphics
Intel Iris Pro Graphics with 4K display capabilities let you edit photos and videos like a professional or immerse yourself in vividly rendered, seamless 3D gameplay, all in brillian 4K on three monitors at once. When you use Intel Iris Pro graphics, you're working smarter, playing harder, and seeing the whole world in high resolution knowing you are using the best Intel Core processors. You've got the best processor graphics with enhanced media conversion and fast frame that delivers picture perfect performance, every time.
Designed for windows 10, so you can get more done
The Intel NUC is designed for Windows 10. You'll experiencecutting-edge performance from the start with fast boot and wake up times, and multitasking that's effortless whether moving between apps, files, or web sites. With support for up to 32GB of RAM, you can get the memory you need for fast map load times or extreme multitasking. And with 4 USB 3.0 ports including a USB charging port, you can use a USB keyboard, mouse and an Intel RealSense camera so you can video chat and collaborate with others as easily as if you were in the same room.
Cut the cords, not the performance
The NUC6i7KTK comes with Intel802.11ac wireless, Intel's fastest wireless available today, so you can connect out of the box and access files, movies and music in the cloud, along with built in Bluetooth 4.2 so yo ucan connect wireless peripherals like headsets and keyboards.
Specifications
Audio 7.1 digital; L+R+mic (F); L+R+TOSLINK (R)
Graphics Intel IRIS Pro 580
LAN 10/100/1000 Mbps
Memory 2 slots (DDR4-2133+ 1.2V, 1.35V SO-DIMM, max 32GB)
Processor Intel Core i7-6770HQ Processor (6M Cache, up to 3.50 GHz)
Series Skull Canyon
Storage 2 x M.2 SSD slot (22x42,80)
Warranty 3 Years
Wireless Intel® Wireless-AC 8260 + BT 4.2
