Product Description
Platform Technology Intel vPro Technology
Type Personal computer
Product Form Factor Small form factor
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
CACHE MEMORY
Installed Size 12 MB
Cache Per Processor 12 MB
RAM
Installed Size 16 GB / 64 GB (max)
Technology DDR4 SDRAM
Effective Memory Speed 2666 MHz
Rated Memory Speed 2666 MHz
Memory Specification Compliance PC4-21333
Form Factor DIMM 288-pin
Slots 4 (Total) / 3 (empty)
Configuration Features 1 x 16 GB
HARD DRIVE
Type SSD - M.2 2280
Capacity 1 x 512 GB
Interface Type PCI Express
Features NVM Express (NVMe)
STORAGE CONTROLLER
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
OPTICAL STORAGE
Type DVD-Writer - SATA
CARD READER
Type 5 in 1 card reader
Supported Flash Memory Cards SD Memory Card, SDHC Memory Card, SDXC Memory Card
MONITOR
Monitor Type None.
GRAPHICS CONTROLLER
Graphics Processor Intel UHD Graphics 630 Dynamic Video Memory Technology
Video Interfaces DisplayPort
HDCP compatible Yes
AUDIO OUTPUT
Sound Output Mode Stereo
Max Sampling Rate 192 kHz
Compliant Standards High Definition Audio
INPUT DEVICE
Type Mouse, keyboard
KEYBOARD
Keyboard Name HP Business Slim Keyboard
Interface USB
MOUSE
Technology Optical
Interface USB
NETWORKING
Ethernet Controller Intel I219-LM
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az
EXPANSION / CONNECTIVITY
Bays 2 (total) / 2 (free) x internal 3.5" 1 (total) / 0 (free) x external 5.25" Slim Line 1 (total) / 1 (free) x internal 2.5"
Slots 1 (total) / 1 (free) x M.2 Card - 2230 (x1 mode) 2 (total) / 1 (free) x M.2 Card - 2280/2230 (x4 mode) 2 (total) / 2 (free) x PCIe 3.0 x1 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) 1 (total) / 1 (free) x PCIe 3.0 x16
Interfaces 4 x USB 2.0 (2 front, 2 rear) (two of them with wake functionality, one of them is fast-charging) 2 x USB 3.1 Gen 1 4 x USB 3.1 Gen 2 (2 front, 2 rear) 2 x DisplayPort 1 x headphones (1 in front) 1 x headphones/microphone (1 in front) 1 x audio line-out 1 x audio line-in 1 x LAN (Gigabit Ethernet) 1 x USB-C 3.1 Gen 2 (1 in front)
PROCESSOR / CHIPSET
CPU Intel Core i7 (8th Gen) 8700 / 3.2 GHz
Max Turbo Speed 4.6 GHz
Number of Cores 6-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Processor Main Features Intel Turbo Boost Technology 2
Chipset Type Intel Q370
MISCELLANEOUS
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Security Slot Type Kensington security slot
Compliant Standards ACPI, CCC, Common Criteria EAL4+, CECP, SEPA, low halogen
POWER
Device Type Power supply
Nominal Voltage AC 120/230 V (50/60 Hz)
Power Provided 250 Watt
Efficiency 92%
Power Factor Correction Yes (active)
OPERATING SYSTEM / SOFTWARE
OS Provided Windows 10 Pro 64-bit Edition
ENVIRONMENTAL STANDARDS
ENERGY STAR Certified Yes
DIMENSIONS & WEIGHT
Width 33.8 cm
Depth 30.8 cm
Height 10 cm
Weight 6.13 kg
DIMENSIONS & WEIGHT (SHIPPING)
Shipping Width 39.9 cm
Shipping Depth 49.9 cm
Shipping Height 23 cm
Shipping Weight 9 kg
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 10 C
Max Operating Temperature 35 C
Humidity Range Operating 10 - 90% (non-condensing)
