Product Description
GENERAL
Platform Technology Intel vPro Technology
Type Personal computer
Product Form Factor Tower
Built-in Devices Speaker
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
CACHE MEMORY
Installed Size 12 MB
Cache Per Processor 12 MB
RAM
Installed Size 32 GB / 64 GB (max)
Technology DDR4 SDRAM - ECC
Effective Memory Speed 2666 MHz
Rated Memory Speed 2666 MHz
Form Factor DIMM 288-pin
Slots 4 (Total) / 2 (empty)
Configuration Features 2 x 16 GB
HARD DRIVE
Type SSD
Capacity 1 x 256 GB
STORAGE CONTROLLER
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
OPTICAL STORAGE
Type DVD-Writer - SATA
CARD READER
Type 5 in 1 card reader
Supported Flash Memory Cards SD Memory Card, SDHC Memory Card, SDXC Memory Card
MONITOR
Monitor Type None.
GRAPHICS CONTROLLER
Interface Type PCIe 3.0 x16
Multi-GPU Configuration 1 single GPU card / integrated GPU
Graphics Processor NVIDIA GeForce GTX 1060 / Intel UHD Graphics 630
Video Memory 3 GB GDDR5 SDRAM
Video Interfaces DVI, HDMI, DisplayPort
HDCP compatible Yes
AUDIO OUTPUT
Sound Output Mode Stereo
Max Sampling Rate 192 kHz
Compliant Standards High Definition Audio
INPUT DEVICE
Type Mouse, keyboard
KEYBOARD
Keyboard Name HP USB Business Slim Keyboard
Interface USB
MOUSE
Technology Optical
Interface USB
NETWORKING
Interface (Bus) Type PCI Express Mini Card (M.2)
Ethernet Controller Intel I219-LM
Wireless LAN Supported Yes
Wireless NIC Intel Wireless-AC 9560
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.11, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac, Bluetooth 5.0
EXPANSION / CONNECTIVITY
Bays 2 (total) / 2 (free) x internal 3.5" 1 (total) / 0 (free) x external 5.25" Slim Line 1 (total) / 1 (free) x internal 2.5" 1 (total) / 1 (free) x external 5.25" x 1/2H
Slots 1 (total) / 0 (free) x M.2 Card - 2230 (x1 mode) 2 (total) / 1 (free) x M.2 Card - 2280/2230 (x4 mode) 2 (total) / 2 (free) x PCIe 3.0 x1 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) 1 (total) / 0 (free) x PCIe 3.0 x16
Interfaces 4 x USB 2.0 (2 front, 2 rear) (two of them with wake functionality, one of them is fast-charging) 2 x USB 3.1 Gen 1 4 x USB 3.1 Gen 2 (2 front, 2 rear) 1 x USB-C 3.1 Gen 2 (1 in front) DisplayPort 1 x headphones (1 in front) 1 x headphones/microphone (1 in front) 1 x audio line-out (1 rear) 1 x audio line-in (1 rear) 1 x LAN (Gigabit Ethernet) 1 x HDMI 1 x DVI-D
MISCELLANEOUS
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Security Slot Type Kensington security slot
Compliant Standards ACPI, CCC, Common Criteria EAL4+, CECP, SEPA, low halogen
POWER
Device Type Power supply
Nominal Voltage AC 120/230 V (50/60 Hz)
Power Provided 500 Watt
Efficiency 92%
Power Factor Correction Yes (active)
PROCESSOR / CHIPSET
CPU Intel Core i7 (8th Gen) 8700 / 3.2 GHz
Max Turbo Speed 4.6 GHz
Number of Cores 6-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Processor Main Features Intel Turbo Boost Technology 2, Intel Smart Cache
CPU Socket LGA1151 Socket
Chipset Type Intel Q370
OPERATING SYSTEM / SOFTWARE
OS Provided Windows 10 Pro 64-bit Edition
ENVIRONMENTAL STANDARDS
ENERGY STAR Certified Yes
DIMENSIONS & WEIGHT
Width 15.4 cm
Depth 37 cm
Height 36.5 cm
Weight 9.86 kg
DIMENSIONS & WEIGHT (SHIPPING)
Shipping Width 29.9 cm
Shipping Depth 47.8 cm
Shipping Height 51.7 cm
Shipping Weight 11.34 kg
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 10 C
Max Operating Temperature 35 C
Humidity Range Operating 10 - 90% (non-condensing)
