Product Description
GENERAL
Type Server
Product Form Factor Blade
Server Scalability 2-way
Hot-Swap Bays Qty 2
CACHE MEMORY
Installed Size L3 Cache - 20 MB
Cache Per Processor 20 MB
RAM
Installed Size 16 GB / 512 GB (max)
Technology DDR4 SDRAM - Advanced ECC
Effective Memory Speed 2133 MHz
Rated Memory Speed 2133 MHz
Memory Specification Compliance PC4-17000
Form Factor DIMM 288-pin
Features Online Spare Memory, Load-Reduced DIMM (LRDIMM), HP SmartMemory
Configuration Features 2 x 8 GB
RAM Supported PC4-17000 - 256 GB registered - ECC PC4-17000 - 512 GB Load-Reduced - ECC
HARD DRIVE
Type No HDD
STORAGE CONTROLLER
Type 1 x SAS-3 - PCIe 3.0 x8
Controller Interface Type SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name HP H244br Smart Host Bus Adapter
RAID Level RAID 0, RAID 1
MONITOR
Monitor Type None.
GRAPHICS CONTROLLER
Graphics Processor Matrox G200eH
NETWORKING
Interface (Bus) Type FlexibleLOM
Ethernet Ports 2 x 10 Gigabit Ethernet
Ethernet Controller HP FlexFabric 536FLB
Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE)
Remote Management Protocol SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL)
Compliant Standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.1Qau
EXPANSION / CONNECTIVITY
Bays 2 (total) / 2 (free) x hot-swap 2.5" SFF
Slots 2 (total) / 1 (free) x CPU 16 (total) / 14 (free) x DIMM 288-pin 2 expansion slot (x16 mode) 1 (total) / 1 (free) x microSDHC Card (internal) 1 (total) / 0 (free) x FlexibleLOM
Interfaces 1 x HP iLO 1 x USB 3.0 (1 internal) 2 x LAN (10Gigabit Ethernet)
MISCELLANEOUS
Compliant Standards ACPI 2.0, FIPS 140-2 Level 2, AES, Triple DES, ASHRAE
OPERATING SYSTEM / SOFTWARE
OS Certified SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Canonical Ubuntu
MANUFACTURER WARRANTY
Service & Support Limited warranty - parts and labour - 3 years - on-site
DIMENSIONS & WEIGHT
Width 5.54 cm
Depth 51.76 cm
Height 18.07 cm
Weight 4.75 kg
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 10 C
Max Operating Temperature 35 C
Humidity Range Operating 10 - 90% (non-condensing)
PROCESSOR / CHIPSET
CPU Intel Xeon E5-2620V4 / 2.1 GHz
Max Turbo Speed 3 GHz
Number of Cores 8-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
