Brand Name: Asus
Chipset Manufacturer: Intel
Chipset Model: C612
Controller Type: Serial ATA/600
Form Factor: SSI EEB
Gigabit Ethernet: Yes
Maximum Memory: 1 TB
Memory Form Factor: LRDIMM
RDIMM
Memory Standard: DDR4-1866/PC4-14900
DDR4-2133/PC4-17000
Memory Technology: DDR4 SDRAM
Multi GPU Supported: SLI
Number of M.2 Interfaces: 1
Number of Memory Slots: 16
Number of Onboard USB 3.0 Ports: 2
Number of PCI Express x16 Slots: 6
Number of SATA Interfaces: 10
Number of Total Expansion Slots: 6
Number of USB 3.0 Ports: 4
Onboard Video: On-board Video Chipset
Processor Socket: Socket LGA 2011-v3
Processor Supported: Xeon
Product Type: Workstation Motherboard
RAID Supported: Yes
Total Number of Onboard USB Ports: 4
Total Number of PCI Express Slots: 6
Total Number of USB Ports: 8
Total Processor Supported: 2
Number of M.2 Interfaces: 1
Number of PCI Express x16 Slots: 6
Number of Total Expansion Slots: 6
PCI Express Standard: PCI Express 3.0
Total Number of PCI Express Slots: 6
Interfaces/Ports
Audio Line In: Yes
Audio Line Out: Yes
Microphone Port: Yes
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 3
Number of PS/2 Ports: 1
Number of S/PDIF Out Ports: 1
Number of SATA Interfaces: 10
Number of USB 2.0 Ports: 4
Number of USB 3.0 Ports: 4
PS/2 Port: Yes
S/PDIF: Yes
Total Number of USB Ports: 8
VGA: No
Memory
Maximum Memory: 1 TB
Memory Form Factor: DIMM
LRDIMM
RDIMM
Memory Speed Supported: 1.60 GHz
1.87 GHz
2.13 GHz
Memory Standard: DDR4-1866/PC4-14900
DDR4-2133/PC4-17000
Memory Technology: DDR4 SDRAM
Number of Memory Slots: 16
Miscellaneous
Form Factor: SSI EEB
Network & Communication
Gigabit Ethernet: Yes
Onboard Interfaces
Number of M.2 Interfaces: 1
Number of Onboard USB 2.0 Ports: 2
Number of Onboard USB 3.0 Ports: 2
Number of SATA Interfaces: 10
Onboard S/PDIF Header: Yes
Onboard Serial Header: Yes
Total Number of Onboard USB Ports: 4
Physical Characteristics
Depth: 330.2 mm
Form Factor: SSI EEB
Width: 304.8 mm
