Model No.
SST-ST1500
Max. DC Output
1500W (Peak 1600W)
Load Range
+3.3V +5V +12V1 +12V2 +12V3 +12V4 +12V5 +12V6 +12V7 +12V8 +5VSB -12V
Max.(Amps)
40A 40A 25A 25A 25A 25A 25A 25A 25A 25A 6.0A 0.5A
Peak (Amps)
/ / 30A 30A 30A 30A 30A 30A 30A 30A 8.0A /
Min.(Amps)
0.8A 0.5A 0.1A 0.1A 0.1A 0.1A 0.1A 0.1A 0.1A 0.1A 0A 0A
Range (%)
±3% ±3% ±3% ±3% ±3% ±3% ±3% ±3% ±3% ±3% ±5% ±10%
Line Reg.(%)
±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p)
50mV 50mV 120mV 120m 120m 120m 120m 120m 120m 120m 50mV 120m
combined +3.3, +5V
280W
combined +12V
1320W/110A (Peak 120A)
Input Voltage
90V~264V
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC(PF>0.95 at Full Load)
Efficiency
85%~88% at 20%~100% loading
MTBF
100,000 hours at 25?(at Full Load)
Operating temperature
0°C ~ 40°C
Protection
Over Current Protection
Over Power Protection
Over Voltage Protection
Under voltage protection
Short Circuit Protection
No Load Protection
Connectors
1 x 24 / 20-Pin Motherboard connector (550mm)
1 x 8 / 4-Pin EPS / ATX 12V connector (750mm)
1 x 8-Pin EPS 12V connector (750mm)
4 x 8/6-Pin PCIE connector (550mm)
4 x 6-Pin PCIE connector (550mm / 150mm)
12 x SATA connector (500mm / 250mm / 250mm)
12 x 4-Pin Peripheral connector (500mm / 250mm / 250mm)
4 x 4-Pin Floppy connector (500mm / 250mm / 250mm / 150mm)
Color
Black (Lead-Free Paint)
Cooling System
Silent 135mm fan
Noise Level
19dBA-34dBA
Dimension
150 mm (W) × 86 mm (H) × 220 mm (D)
Weight
4.2Kg
Form factor
ATX PS/2
Certification
80 PLUS Silver
Other
GPU Support list
Haswell CPU support
| |
| |
|
|
|
|
|
| |
|
