Product Description
GENERAL
Type PC barebone
Product Form Factor Mini PC
Built-in Devices Infrared receiver
CACHE MEMORY
Installed Size 2 MB
Cache Per Processor 2 MB
RAM
Installed Size 0 MB / 8 GB (max)
Technology DDR3L SDRAM
Form Factor SO-DIMM 204-pin
Features Dual channel memory architecture
HARD DRIVE
Type No HDD
STORAGE CONTROLLER
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
CARD READER
Type Card reader
Supported Flash Memory Cards SDXC UHS-I Memory Card
MONITOR
Monitor Type None.
GRAPHICS CONTROLLER
Graphics Processor Intel HD Graphics 500
Video Interfaces VGA, HDMI
Max Monitors Supported 2
AUDIO OUTPUT
Sound Output Mode 7.1 channel surround
Compliant Standards High Definition Audio
NETWORKING
Wireless LAN Supported Yes
Wireless NIC Intel Dual Band Wireless-AC 3168
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2
Compliant Standards IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2
EXPANSION / CONNECTIVITY
Bays 1 (total) / 1 (free) x internal 2.5" 1 (total) / 1 (free) x internal M.2 2230
Slots 2 (total) / 2 (free) x SO-DIMM 204-pin
Interfaces 4 x USB 3.0 - Type A (2 front, 2 rear) (one of them is fast-charging) 2 x USB 2.0 (2 internal) 1 x HDMI 1 x headphones/microphone - mini-jack 1 x LAN (Gigabit Ethernet) - RJ-45 1 x VGA 1 x TOSLINK output 1 x SATA-600 (1 internal)
MISCELLANEOUS
Included Accessories VESA mounting kit, processor badge
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Compliant Standards ACPI
POWER
Device Type Power adapter
Power Provided 65 Watt
MANUFACTURER WARRANTY
Service & Support Limited warranty - 3 years
PROCESSOR / CHIPSET
CPU Intel Celeron J3455 / 1.5 GHz
Max Turbo Speed 2.3 GHz
Number of Cores Quad-Core
CPU Qty 1
Max CPU Qty 1
Processor Main Features Intel Virtualization Technology, Intel AES New Instructions
DIMENSIONS & WEIGHT
Width 11.5 cm
Depth 11.1 cm
Height 5.1 cm
