TECHNOLOGY
Projection System: Epson 3LCD, 3-chip technology
LCD Panel: 0.95-inch wide panel with MLA (D7, C2 Fine)
OPTICAL Zoom: 1 - 1.61 (Powered Optical Zoom)
Screen Size: 60" to 500"
Projection Distance: 100" screen 3.68 m - 5.97 m
Throw Ratio: 1.71 (Zoom:Wide), 2.78 (Zoom:Tele)
Projection Lens F Number: 1.65 - 2.51
Projection Lens Focal Length: 36.00mm-57.35mm
Focus Method
Powered Focus: Offset
Lens dependant
Colour Light Output: 8,500 Lumens
White Light Output: 8,500 Lumens
Resolution: WXGA
Native Aspect Ratio: 16:10
Contrast Ratio: 5,000:1
Lamp Hours: Normal/Eco: 2,500/3,500 Hours
Lamp Type: 2 x 340 W UHE
Keystone Correction
Vertical: -30 to +30 degrees
Horizontal: -20 to +20 degrees
Lens Shift
Vertical: -70% to +70% (Powered)
Horizontal: -20% to +20% (Powered)
Tilt Angle: -3.5 to 3.5 degrees
CONNECTIVITY
Input: Video 1 x RCA (Yellow), 1 x S-Video, 1 x 5BNC, 1 x Component (via D-sub 15-pin)
Input: Computer 1x D-sub 15-Pin (RGB)
Input: Digital 2 x HDMI
Input: Audio 2 x HDMI
Input: Control 1 x RS-232C, 1 x RJ45, 1 x Remote (Stereo mini Jack)
Wireless Connectivity: Optional
Output: Video 1 x Monitor Out (via D-sub 15-pin)
ADVANCED FEATURES
EasyMP Network & Control: Yes
EasyMP Network Projection: Yes
Split Screen: Yes
Edge Blending: Yes
Arc Correction: Yes
Super Resolution: Yes
Frame Interpolation: No
360 Degrees Projection: Yes
Instant Off: Yes
Direct Power On/Off: Yes
Security:-
Kensington®-style lock provision
Padlock & Security cable hole
Password protect function
Colour Modes: Photo, Presentation, Theatre, Dynamic, sRGB, Multi-Projection, DICOM SIM
GENERAL
Dimensions D x W x H: 534 x 734 x 167 mm (not including foot, projection lens and handle)
Weight: Approx. 22 kg (Including lens)
Lamp Warranty: 12 months or 750 hours*
Projector Warranty: 4 Years or 10,000 Hours*
Power Consumption: Lamp on
Normal/Eco: 911/738W
Power Consumption: Standby 0.49W (communication off)
Noise Level: Normal: 40dB / Eco: 35dB
| |
| |
|
|
|
|
|
| |
|
