Product Description
PRODUCT DESCRIPTION
The Multi Mode OM1 cables are designed to support Gigabit Fibre & ethernet channel, the cables are capable of supporting 1Gigabit applications upto over 25 m length.The ALOGIC Fibre Cables are constructed with the high quality components such as genuine Corning Inficore 3 glass and high grade connectors with ceramic ferrules to ensure the maximum performance accuracy and durability. The cables meet or exceed industry standard specifications; each cable is individually tested for maximum reliability and comes with performance reports.The ALOGIC OM1 Patch Cables are available in various lengths starting from 1m to 2 m length
PRODUCT SPECIFICATION
Connector type
SC, ST
Wavelengths
62.5 µm (OM1)/125 µm
Attenuation
At 850 nm: <3.5 dB per km
At 1300 nm: <1.0 dB per km
Insertion loss
<0.2 dB per 300 m @ 850 nm or 1300 nm
Fiber
Glass
Number of fibers
2
Jacket
LSZH (Low Smoke Zero Halogen)
Cable outer diameter
2mm +/-0.2mm
Safety
ETL/c-ETL
Warranty
Lifetime
PRODUCT FEATURE
* Multi Mode OM1 fibre optic cable.
* Available in various lengths starting from 1m to 20m length
* Low Smoke Zero Halogen Jacket for minimal toxic emissions in case of fire.
* 100% optically tested and provided with test reports.
* Life Time warranty.
