Product Description
Specifications
Network Protocol and Standards Compatibility
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x full-duplex flow control
Interfaces
GS724T: 24 RJ-45 connectors for 10BASE-T, 100BASE-TX, and 1000BASE-T (Auto Uplink on all ports)
GS716T: 16 RJ-45 connectors for 10BASE-T, 100BASE-TX and 1000BASE-T (Auto Uplink on all ports)
2 Dual Personality SFP slots for fiber Gigabit Ethernet modules
Administrative Switch Management
IEEE 802.1D Spanning Tree Protocol
RFC 1157 SNMP v1, v2c
RFC 1213 MIB II
RFC 1643 Ethernet Interface MIB
RFC1493 Bridge MIB
Private Enterprise MIB
Jumbo Frame Support (up to 9216 bytes)
IEEE 802.1Q Tag VLAN
GS716T: 64 Static VLANs
- Supports 16 port-based VLAN
GS724T: 128 Static VLANs
- Supports 24 port-based VLAN
IEEE 802.1p (Class of Service)
DSCP - L3 QoS
Port-based QoS (options High/Normal)
Port Trunking - Manual as per IEEE802.3ad Link Aggregation
DHCP client function
Access Control: Trusted MAC
Broadcast storm control (GS724T only)
Port mirroring (many-to-one)
Port setting
Web-based configuration, anywhere on the network
Smartwizard Discovery Utility program auto discovers devices (up to 254 agents/switches); set system configuration to each agent
Configuration backup/restore (easy to configure more than one switch)
Password access control and Restricted IP Access List
Firmware upgradeable
Active Flow Control
Full-duplex IEEE 802.3x pause frame flow control
Half-duplex back-pressure control
Performance Specifications
Forwarding modes: Store-and-forward
Bandwidth: GS724T = 48 Gbps, GS716T = 32 Gbps
Network latency:
GS716T average latency 34.8 us for 100 Mbps with 64 bytes
GS724T average latency 10.59 us for 100 Mbps with 64 bytes
Buffer memory: 256 KB embedded memory per unit
Priority queues: 4
Priority queuing: Weighted Round Robin (WRR)
Address database size: 8,000 media access control (MAC) addresses per system
Addressing: 48-bit MAC address
Mean time between failures (MTBF):
- GS716T = 59,500 hours (~6.8 years)
- GS724T = 59,500 hours (~6.8 years)
Acoustic Noise:
- GS724T = 41 dBA
- GS716T = 42.5 dBA
LEDs
Unit: Power
Per port: Link, activity, speed, duplex
Power Supply
Dimensions (h x w x d):
- GS716T: 43 x 440 x 205 mm (1.7 x 17.3 x 8.1 in)
- GS724T: 43 x 440 x 260 mm (1.7 x 17.3 x 10.2 in)
Weight:
- GS716T: 3.5 kg (7.7 lb)
- GS724T: 3.6 kg (7.9 lb)
Environmental Specifications
Operating temperature: 32° to 104°F (0° to 40° C)
Storage temperature: -4° to 158°F (-20° to 70° C)
Operating humidity: 90% maximum relative humidity, non-condensing
Storage humidity: 95% maximum relative humidity, non-condensing
Operating altitude: 10,000 ft (3,000 m) maximum
Storage altitude: 10,000 ft (3,000 m) maximum
Electromagnetic Compliance
CE mark, commercial
FCC Part 15 Class A
VCCI Class A
EN 55022 (CISPR 22)
EN 55024 (CISPR 24)
C-Tick
Safety Agency Approvals
UL listed (UL 1950)/cUL
IEC 950/EN 60950
CE mark, commercial
CUL 60950 (Listed)/EN 60950 (Low Voltage Directive)
Modules
NETGEAR ProSafe AGM731F 1000BASE-SX SFP GBIC Module with LC connectors for 50um or 62.5um multi-mode fiber cable
NETGEAR ProSafe AGM732F Fiber 1000BASE-LX SFP GBIC Module with LC connectors for 9um single-mode fiber cable
NETGEAR ProSafe AGM733 Fiber 1000BASE-ZX SFP GBIC Module with LC connectors for 9um single-mode fiber cable
Warranty
NETGEAR Lifetime Warranty†
ProSupport Service Packs Available
